Isolation Explosion-proof Pressure Sensor PCM301
Features
■ All stainless steel welded structure
■ High strength, anti-vibration
■ Exd II BT6 certified
■ -100kPa…0~10kPa…100MPa
■ Output: 4~20mA(16~36VDC)
■ IEC 61000-6-3
■ Protection: IP65
Applications
■ Equipment support
■ Hydraulic and pneumatic equipment
■ CNG pipeline network
■ Compressor
■ Natural gas filling station equipment
Exd II BT6 certification flameproof pressure transmitter,China isolation explosion-proof pressure transmitter,piezoresistive silicon isolation explosion-proof pressure transmitter,CNEX transmitter
China Wotian factory flameproof pressure transmitter specially designed for explosion-proof places, adopting integrated all-welded structure and high-stability piezoresistive silicon pressure sensor, with high strength, anti-vibration, small size, good sealing performance and long-term stability
Product Parameters
Performance parameters | |||
Pressure range | -100kPa…0~10kPa…100MPa | ||
Pressure reference | Gauge pressure, Absolute pressure, Sealed gauge pressure | ||
Supply & output | 4~20mA(16~36VDC) | ||
1~5V, 0~5V(12~36VDC) | |||
Accuracy | ±0.5%FS(typ.); ±1%FS(max.) | ||
Hysteresis & repeatability | ≤±0.1%FS | ||
Temp. drift | ≤±1.5%FS(@-20℃~85℃) | ||
Response time | ≤1ms(up to 90%FS) | ||
Service life | ≥10×106 pressure cycles | ||
Ambient temp. | -20℃~80℃ | ||
Medium temp. | -30℃~105℃ | ||
Storage temp. | -40℃~85℃ | ||
EMC-interference | IEC 61000-6-3 | ||
EMC-immunity | IEC 61000-6-2 | ||
Vibration resistance | ≥100MΩ/500VDC(200MΩ/250VDC) | ||
Shock | 100g(11ms) | ||
Protection | IP65 | ||
Material | 304 | ||
Max. mounting torque | 25Nm | ||
Ex-proof | ExdⅡBT6 | ||
Structure | |
Dimension In mm |
|
Application of damper |
Application
Cavitation, liquid hammer and pressure peak may occur in air or hydraulic systems with varying flow rates, such as the rapid closing of valve or the start and stop of pump. Even at relatively low operating pressures, these problems may occur at the entrance and exit.
Application of damper (cont.) |
Media condition
In the liquid containing particles, nozzle clogging may occur. The vertical mounting of pressure transmitter minimizes the risk of clogging because the flow of fluid happens in initial start only, the volume of the rear of the nozzle is fixed and the nozzle has a relatively large aperture (1.2 mm).
The effect of medium viscosity on response time is small. Even if the viscosity reaches 100 CST, the response time will not exceed 4 ms.
Pressure range selection | |||||
Pressure range code | Pressure reference | Pressure range | Overpressure | Remark | |
35k | G | 0~35kPa | 300％FS | ||
70k | G | 0~70kPa | 300％FS | ||
100k | G, A | 0~100kPa | 200％FS | ||
160k | G | 0~160kPa | 200％FS | ||
250k | G, A | 0~250kPa | 200％FS | ||
400k | G | 0~400kPa | 200％FS | ||
600k | G | 0~600kPa | 200％FS | ||
1M | S | 0~1MPa | 200％FS | ||
1.6M | S | 0~1.6MPa | 200％FS | ||
2.5M | S | 0~2.5MPa | 200％FS | ||
6M | S | 0~4MPa | 150％FS | ||
10M | S | 0~6MPa | 150％FS | ||
16M | S | 0~10MPa | 150％FS | ||
25M | S | 0~25MPa | 150％FS | ||
40M | S | 0~40MPa | 150％FS | ||
60M | S | 0~60MPa | 150％FS | ||
100M | S | 0~100MPa | 150％FS | ||
Note: G stands for gauge pressure, A, absolute pressure, S, sealed gauge pressure.
